FINN-POWER FP120, THE LEGEND IS REBORN



New FP120 is compact and easy to use, designed to handle the highest production volumes.



Unbeaten in terms of speed, precision, durability and quality. Depending on available space, or the space need behind the machine, the hydraulic and crimping unit can be separated or combined.



Control:
ICC (7” touchscreen), ICC (12” touchscreen) or SCC (3,5” display + control wheel)



FP120 also available in following configurations:

Z-model with separate crimping head and hydraulic unit
HB/HS-model with horizontal back and horizontal side



Standard Features:

Pressure crimping ICC1

Step crimping ICC2

QuickChange-tool

Electric backstop device

MirrorDie racks



Options:

Foot pedal

Front table

Quality die rack

Fitting storage

Mechanical back stop device

Auto greasing G3

Oil cooler **

Combi unit (crimping and hydraulic unit combined)

Pinning support mandrel

Horizontal Back layout HB

Horizontal Side layout HS

Remote control (R1, R2)

Quality control ICC3

Graphical quality control ICC4

Interface pack ETH (Communication TCP/IP & UDP)

A3 signal (cable not included)Bar Code Reader BCR

Speed adjustment **Oil Condition Monitoring OCM
Industry 4.0

Camera (requires 12” display)

Safety Scanner** Will have impact on motor size,hydraulic unit dimensions and weight.
** Will have impact on motor size,
hydraulic unit dimensions and weight.

FP120

  • Max crimping dia (1) 87mm
    Max crimping force 2800KN
    Cycle time 10 mm (s) (2) 1.8 (S-model: 1.6)
    Hose size ID 2" (4SH)
    Die set series 32
    Max opening (mm) (4) +68
    Max opening without dies 167mm
    Master die D/L 99/97mm
    Motor Power  6.5 kW
    Oil tank volume 135L

    Dimensions (Machine)

    Length

    Width

    Height


    881mm

    664mm

    1561mm

    Weight (Machine)                      654 Kg

    Dimensions (Hydraulic Unit)

    Length

    Width

    Height


    782mm

    751mm

    1063mm

    Weight (Hydraulic Unit) 220 Kg
    Weight (Compact setup)        1060 Kg

    1) With standard dies. Crimping range can be increased with special dies.
    2) Theoretical with 10mm cycle.
    3) See table for die set data.
    4) Maximum opening is the total die travel. Add this value to the minimum crimping diameter of the die set used. The result is the maximum opening of the machine with die set in place.
